Night Hawk Relay Patch Loom

RRP: $19.00

Part Number: NHWA01RPL

The Night Hawk Relay Patch Loom is a prewired, OEM quality wiring patch solution to be installed into vehicles displaying intermittent operating issues due to a Pulse Width Modulated (PWM) signal on the high beam circuit of the vehicle headlights. A plug-and-play solution suitable for use with Night Hawk VLI/VCT/VBP wiring systems and Night Hawk High Beam Adapters.

Part Number: NHWA01RPL Category: Product ID: 20203

Description

The Bushranger Night Hawk Relay Patch Loom is a prewired, OEM quality wiring patch solution to be installed into vehicles displaying intermittent operating issues due to an inconsistent Pulse Width Modulated (PWM) signal on the high beam circuit of the vehicle headlights.

It is designed to be plug-and-play with our range of Night Hawk high beam adaptors, it is inserted between the vehicle’s high beam signal and the Night Hawk Variable Series wiring system, providing a clean 12V high beam signal from the battery to trigger the wiring system. Featuring an automotive 12V relay, weatherproof fuse holder, 105°C rated wiring, quality connectors and protected with corrugated split tubing, this patch loom is supplied ready to install.

Some known vehicles that may display intermittent issues include 2011 onwards Ford Ranger’s, VW Amarok’s and Jeep Wrangler’s, however other vehicles may also be affected. It is always recommended to check if the fault is present before installing this patch loom to avoid unnecessary installations.

SPECIFICATIONS

  • Specifically designed to suit Night Hawk Variable Series wiring systems and Night Hawk high beam adaptors.
  • No cutting, splicing, soldering or wire-tapping is required.
  • Suitable for 12VDC automotive wiring systems.
  • 12VDC relay with 105°C rated wiring.
  • Weatherproof fuse holder and corrugated split tubing for greater protection.

GUIDES

Instruction manual: Instructions Relay Patch Loom
